* Please visit the product pages on our website for the most up-to-date product information
PATCHCORDS/MOLDED CABLES
44
Audio and Video Patchcords
Features and Benefits - Audio
? 110 ohm impedance-matched
digital patchcords meet AES/EBU
interface standards for digital
patching
? Available with a variety of plug
terminations, plug finishes, cord
lengths and cable colors, the
patchcords offer design flexibility
VP1BK
20Q
? Premium quality cable insures high
reliability and greater flexibility
TT1BK
TT740
18Q
TT120
Specifications
Standard plug terminations are
single 3-conductor 1/4" and TT?
Nickel-plated plugs (standard),
brass and gold-plated (optional)
Cable jacket material is PVC.
Black is standard with other
colors available
Features and Benefits - Video
? Designed and built to highest
quality standards for efficient
video signal transmission
? Cable type is RG59 (75W)
? Rugged nickel-plated handles
with knurled area for positive
finger grip
A wide variety of audio patchcords
and molded cable assemblies are
available. Some of the more popular
versions are the 18Q and 20Q Series
for professional 1/4" patching, the
TT* and TTD Series for TT or bantam
AES/EBU digital patching. The VP
and VMP Series offer exceptional
performance for video signal patching.
Ordering Information
MD3
MD6
? Available in standard size or
midsize styles
Specifications
Materials
Housing: Nickel-plated,
copper alloy
Contact Pin: Gold-plated,
copper alloy
Boot: Thermoplastic, in black
and colors
Video Patchcords
Part Number
VP3**
VP4**
VP5**
VP6**
VP7**
VP8**
VP9**
VP10**
VSPP
VMP1**
Type
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Midsize
Part Number
VMP2**
VMP3**
VMP4**
VMP5**
VMP6**
VMP7**
VMP8**
VMP9**
VMP10**
VMPP
Type
Midsize
Midsize
Midsize
Midsize
Midsize
Midsize
Midsize
Midsize
Midsize
Midsize
When ordering, add the following for cable color: BK-Black, BL-Blue, R-Red, O-Orange,
Y-Yellow, GN-Green, P-Purple, GY-Gray
